JTAG PIN Identification
My Setup Parrot Linux Arduino UNO Broadlink RM Mini Software Arduino IDE JTAGEnum ( https://github.com/cyphunk/JTAGenum ) JTAG PINS to be Identified TCK - Test Clock TMS - Test Mode TDI - Test Data IN TDO - Test Data Out GND - Ground Hardware Connection Set up Connect Laptop and Arduino (USB cable) Arduino Digital PIN (any 5 pins) to RM Mini (5 pins) [Except 1 - VCC and 1 - GND] Note: If you are using JTAGENUM, the JTAGenum sketch uses the DIGITAL PIN from 2 to 11. Refer the line number 72(ino file) Software Connection Set up Download the INO sketch from the github Open the Arduino IDE and Load the downloaded JTAGEnum sketch Choose the correct Serial Port and Board Compile and Upload the sketch Open the Serial Monitor Set the correct baud rate Enter the command to scan ("s") Arduino PIN Layout Digital PIN 2(Black) Digital PIN 3(Whi...
